What is the multimode fiber model comparison table
OM1, OM2, OM3, OM4, and OM5 multimode fibers differ in core size, bandwidth, maximum distance, optical source, and typical applications.Fiber TypeCore Size (µm)Bandwidth (MHz·km)Max Distance (10G Ethernet)Optical SourceJacket ColorTypical ApplicationsOM162.5200 @ 850 nm33 mLEDOrange100 Mb/s Ethernet, legacy LANsOM250500 @ 850 nm82 mLEDOrange1 Gb/s Ethernet, short-distance LANsOM3502000 @ 850 nm300 mLaser-optimized (VCSEL)Aqua10 Gb/s Ethernet, data centersOM4504700 @ 850 nm550 mLaser-optimized (VCSEL)Aqua10/40/100 Gb/s Ethernet, high-speed data centersOM5504700 @ 850 nm (supports SWDM)550 mLaser-optimized (VCSEL)Lime Green40/100 Gb/s Ethernet, SWDM, future-proof data centersKey Notes:OM1 and OM2 are legacy fibers, primarily using LED sources, suitable for short-distance Ethernet connections within buildings or campuses .OM3 and OM4 are laser-optimized multimode fibers (LOMMF) designed for VCSELs, supporting higher data rates and longer distances, commonly used in modern data centers .OM5 introduces Short Wavelength Division Multiplexing (SWDM), allowing multiple wavelengths over a single fiber, enabling higher aggregate bandwidth without additional fibers .Jacket colors help identify fiber types: orange for OM1/OM2, aqua for OM3/OM4, and lime green for OM5 .Bandwidth is measured at 850 nm, the standard wavelength for multimode fiber, and determines the maximum data rate over a given distance . This table provides a clear overview for selecting the appropriate multimode fiber type based on distance, speed, and application requirements in enterprise networks and data centers.
